DYWIDAG SPEED EDGE FORMWORK SYSTEM

Bluebay Building Products are exclusive stockists of the Dywidag Speed Edge Formwork system in the UK.



Speed Edge Formwork is an innovative solution that is made from sheet steel for the installation of permanent lateral formwork for reinforced concrete base and floor slabs in structural and civil engineering situations.

  • Available in Heights of 140mm to 500mm & standard lengths 2.25mt long.
  • Completely self-supporting, eliminating the need for props and vastly reducing the need for excavation and back filling.
  • Available in Heights of 140mm to 500mm
  • Quick installation time vs traditional ply and prop method. One person can install.
  • Corners simply bent into shape.
  • Complex slabs easily formed
  • No striping needed

[3d-flip-book mode=”fullscreen” id=”114510″ ][/3d-flip-book]


GDA ACTITEX BENONITE STRUCTURAL WATERPROOFING

Bluebay Building Products are the exclusive suppliers of the GDA Actitex Bentonite Structural Waterproofing Systems in the UK & Ireland

[3d-flip-book mode=”fullscreen” id=”114383″ ][/3d-flip-book]


MACCAFERRI GEOTEXTILES & GEOGRIDS SUPPLIER

Bluebay Building Products, are a leading supplier of Geotextiles & Geogrids for environmental protection, erosion control, ground reinforcement & stabilisation.

We work very closely in partnership with our partner Maccaferri to provide you with design, installation and technical support for your soil engineering project and would be please to provide you with a competitively priced solution.

Maccaferri manufacture and supply high quality durable materials which: Enhance the service life of the works Reduce environmental impact provide client reassurance Many of the products are certified by international or local accreditation bodies.



Macaferri engineers and technicians are available to answer your questions and provide technical support. This guide provides a short introduction to the range of Maccaferri products. It includes only a proportion of the full range they offer. Detailed technical information, brochures, case histories and more are available.

The Maccaferri range is widely available throughout the UK on a next day service from our four
strategically placed distribution depots.

Maccaferri are the largest gabion basket manufacturer worldwide we can supply or using their design and supply service.

 Maccaferri have their our own Macweb soil cell in stock in the UK in 100,150 and 200mm depths,

 Maccaferri are the sole UK distributor for Enkamat materials and also have their own range of biodegradable erosion mattings

 Maccaferri have their own linear composites factory based in Yorkshire that manufactures their uniaxial geogrids such as paragrid, paralink and paradrain, which used for reinforced earth or basal reinforcement system solutions

[3d-flip-book mode=”fullscreen” id=”114380″ ][/3d-flip-book]


UPVC SACRIFICIAL SCREED RAIL SYSTEM FROM BLUEBAY

K-FORM UPVC Screed Railing provides the construction industry with an economical, efficient and environmentally friendly alternative to steel and timber formwork.

Made from 100% recycled materials, K-FORM is lightweight, durable and does not require removal after placement of concrete. It is easily cut to length on site and has pre-drilled holes in the vertical face for placing steel dowels bars and in the base for anchoring. K-FORM’s patented design features a removable top strip for joint sealing and its unique end clips allow for quick and easy installation.

Intended to be used with all types of screeds including; twin beams, roller strikes, vibro strikes, etc. K-FORM’s K135, K85 and K35 sacrificial railing replaces steel forms where joints are needed.

Bluebay are working in partnership with K-FORM to supply their range of UPVC Sacrificial Screed Rail Systems and Accessories.

[3d-flip-book mode=”fullscreen” id=”114425″ ][/3d-flip-book]




SPECIALIST SUPPLIER OF BAG COLUMN FORMERS

Bluebay Building Products, are a leading supplier of BAG® Column Formers. BAG® Column Formers are a single use formwork system that gives an excellent smooth fair face surface finish. Their Column Formers are manufactured by welding together several layers of high quality polyethylene coated kraft paper, which are spirally wound and bonded together by heating the polyethylene. Once this step is complete, a water resistant foil is also spirally wound over the kraft paper, sealing the column against humidity. This manufacturing process requires no additional adhesives which reduces the wall thickness, making the BAG ® Column Formers light and easy to handle.

Advantages of BAG Column Formers:

  • – Light easy to handle as opposed to steel shuttering.
  • – Labour saving.
  • – Easy to strip, no mould oils required.
  • – Quality fair faced finish.
  • – Can be used for protective cover for the completed columns.

Installing BAG Column Formers:



BAG ® Column Formers are very light and can be transported without any handling equipment.

The tubes can be secured on the base using timber which is fixed to the floor or decking as required. The top of the tube can either be secured using timber or with our own tension belt system. When using our system you are able to fix three sloped bearings with a 120 degree angle. Normally two fixing points are sufficient at a 90 degree angle. If the Column Former is 7 metres or more we recommend that an additional fixing point is used at the middle point of the tube.

[3d-flip-book mode=”fullscreen” id=”114377″ ][/3d-flip-book]


INTRODUCING TERWA ALLIGATOR MECHANICAL COUPLERS

Bluebay are now stocking Terwa Alligator Couplers – a splicing coupler designed to meet the requirements of BS8110 and EC2 for mechanical couplers used to form butt joints in reinforcement steel.

The Alligator Couplers are supplied in a range of sizes to suit the reinforcement steel range 10mm to 40mm inclusive. The system is ideally suited to minimising steel congestion in heavily reinforced structures, providing simple connections for prefabricated reinforcement steel and facilitating the removal and replacement of damaged reinforcement steel in repair contracts. The mechanical connection is made by inserting the rebar into each end of the coupler and tightening the lock shear bolts by hand, once satisfied that the joint is suitably assembled and aligned, the lock shear bolts are tightened up with suitable impact driver. The bolt heads shear off at the desired torque setting, giving a clear indication that installation is complete and satisfactory.

[3d-flip-book mode=”fullscreen” id=”114374″ ][/3d-flip-book]


INTRODUCING THE 2020 BLUEBAY PRODUCT CATALOGUE

Bluebay Building Products are pleased to announce the launch of its new 2019 product catalogue, with over 200 pages it is specifically designed to give contractors, architects and specifiers information on its extensive range of building, civil engineering & construction products.

The new catalogue is the latest and largest brochure to showcase Bluebay’s current range of products and includes valuable information on product considerations as well as up to date technical information to ensure products are specified accurately.

Paul Thomas, Group Technical Director, said: “We really wanted to provide our customers with an indispensable guide to our products that would simply make their jobs easier. In addition to detailed product specifications, the brochure includes helpful technical advice to make ordering a lot easier.

The new brochure also includes our new “Solco” range of technical specification products as well as important information about the latest industry legislation and building regulations, including product approvals & accreditations.
