Brickforce – Masonry Reinforcement

Structural Brickforce is manufactured in 5 diameters, and with this range of sizes it is possible to get closer to the optimum solution, thus reducing material costs.

This flexibility gives the design Engineer the ability to save on other materials. For example, wind posts can be designed out, top rails removed in laterally loaded panels and minimum wall widths maintained. Brickforce is manufactured with CARES approval.

Important Notes:

Galvanised supplied:
bundles of 25, 2.7m Long

Stainless Steel supplied:
bundles of 20 strips, 2.7m long.

Brickforce is now produced with a characteristic tensile strength of 500 N/mm.

Brickforce – Galvanised

Brickforce – Stainless Steel

Wire Size

Width(s)

Wire Size

Width(s)

3.0mm

60 / 100 / 150 / 175mm

3.0mm

60 / 100 / 150175mm

3.58mm

60 / 100/ 150 / 175mm

3.58mm

60 / 100/ 150 / 175mm

4.0mm

60 / 100 / 150 / 175mm

4.0mm

60 / 100 / 150 / 175mm

4.5mm

60 / 100 / 150 / 175mm

4.5mm

60 / 100 / 150 / 175mm

5.0mm

60100 / 150 / 175mm

5.0mm

60100 / 150 / 175mm
