Concrete Square Concave Spacer

A Strong Extruded Fibre Reinforced Concrete Spacer

A very strong Spacer in manufactured in extruded fibre concrete with concave square section suitable for medium / heavy horizontal reinforcements. Available in two lengths of 90cm or 100cm. The tapered section improves the adhesion of the cement matrix, other sizes can be made on request.

Bluebay Extruded Fibre Reinforced Concrete Spacers ensure that the specified concrete cover to the reinforcement for structures and structural elements is achieved, both before and during concreting. These spacers help to guarantee the durability of all structures. Spacers made of fibre concrete have an optimum material compatibility with in-situ concrete. Bluebay spacers are produced with strength and durability properties to match most site and precast concrete applications. The outstanding material properties of fibre reinforced concrete include:

• High compressive strength, accurate dimensional tolerances, excellent  chemical resistance
• Excellent bond with concrete, no hairline cracks between the spacer and concrete, suitable for impermeable concrete
• Fire resistant to the highest requirements specified in EN13501-1:2002 – Class 1A
• The performance meets the requirements of BS 7973 (British Standard for Spacers)

Available in lengths: 900mm or 1000mm lengths, other lengths available

Cover sizes of :- 30mm, 35mm, 40mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm
